WHY CLIMB? When you can TILT your way to the TOP!

LM SERIES SELF SUPPORTING TOWERS

LM Series Self Supporting Tower / Tilt-Over Mast by Beacon Pole - Very Unobtrusive - Uncomplicated

LM SERIES SELF-SUPPORTING TOWERS

The LM-Series offers an easier, safer, more economical and lower cost installation solution. We offer towers made in the USA with solid engineering solutions that rise to meet the industry standard. Although, there are several internet tower options on the market, there are three things that make our patented tower unique.

1. SAFETY

Our towers do not require a climber to mount the receiver/antenna. The tower can easily be lowered by the owner, the receiver mounted to the tower, then erected vertically. Once vertical, the tower can be rotated from the ground to dial in the best reception for the receiver. That’s the patented part of the design.

2. APPEARANCE

There are no ugly supports or guyed wires necessary for anchoring the tower to the ground. Our towers are much more aesthetically appealing than anything else offered on the market. Most other towers either have to be attached to the side of an existing structure, or require 3-4 sets of support wires extending outward from the tower itself. These guy wires require a much larger footprint and substantial foundations to place the tower in any particular area. Our towers require a very limited amount of space.

3. MOST ECONOMICAL

For comparable towers of similar height, our towers are significantly less expensive and the installation process is much less complicated allowing for even more savings. The foundation consists of a 12” diameter hole 6 to 7ft deep, poured full with concrete. Setting the foundation and base section of the tower is very similar to setting a large fence post or gate post. Although less complicated, caution is necessary and safety is of utmost importance.

P R O D U C T S

The LM-Series self-supporting towers offer a safe, lower cost and less complicated installation solution. We offer towers made in the USA with solid solutions that meet the industry standard.

Model LM-3

50' Self-Supporting Tilt-Over Tower

$5333.33

** INTRODUCTORY PRICE of $2580/tower with a purchase of 10 minimum.

Model LM-4

75' Self-Supporting Tilt-Over Tower

$7,333.33

Model LM-5

60' Robust MicroPop

DIY Installation Kit (Optional)

Not necessary if you already have all the tools listed.

Downloadable DIY Installation Instructions Available Here or Emailed Upon Request

¨ $850 each Installation Kit

Click HERE if you're ready to shop

INSTALLATION by Beacon Pole

** FOR A LIMITED TIME **

ASK how you can get FREE INSTALLATION within 50 mile radius of Bellville, TX

Includes:

¨ All Hardware, Tools & Materials

¨ Concrete Work, Tower Assembly, Installation

¨ Trenching

¨ 2 each—Up To 300 ft Ethernet Cat 5 or 6 Wire From Tower To Structure

¨ Technicians & Labor

¨ Freight & Travel Time Within 50 miles

¨ $4/mile over 50 Mile Radius

¨ One Year W

Self-Supporting Towers / Tilt-Over Masts

FEATURES

No climbing required to install, erect or service.
No guy wires or support from buildings required.
Cost effective with our DIY Installation Option.
Our most popular tower/mast with an unobtrusive design.
Range up to 75’, depending on radio/antenna size.
About 6 man-hours to install and set-up.
A lockable, tilt-over, hinged design allows servicing radio/antenna from the ground.
Azimuth is adjustable from the ground.
Tower/mast sections are galvanized for long life.
Cables are routed internally for protection and appearance.
No excavation & No pouring a large heavy concrete base.
Requires a 6-7 foot deep post hole with 5-6 sacks of premix.
Tower/mast sections are galvanized for long life.
LM-4 Tower/mast is intended to support a single Fixed Wireless Internet radio/antenna 16 inches in diameter at 60 feet, or 10 inches in diameter at 75 feet above the ground.
Made In The USA.
Veteran Owned.
Patented.
One Year Limited Warranty On Parts If Installed According to our Installation Instructions.

Self Supporting Tower / Tilt-Over Mast with Unobtrusive Custom Design

WHO NEEDS a Self-Supporting Tower / Mast?

CPE (Customer Premises Equipment) for Fixed WISPs (Wireless Internet Service Providers)
Wireless Point-to-Point Ethernet Links
Micro-PoP Applications
Neighborhood 5G Access Points
Broadband Last Mile
Cell Phone Booster
Job site Telecommunications
Barge Telecommunications
Remote Oil & Gas Well Monitoring
Weather Stations
Satellite Antennas
Outdoor Industrial Lighting
Outdoor Security Cameras or Game Cameras
Fire Department Radio
Ham Radio Fans
Temporary Towers needed for Disasters

** We Supply Towers/Masts. We Are Not An Internet Service Provider.

Tower Antenna installed on our LM4 Series self supporting tower / tilt over mast by Beacon Pole

Our OBJECTIVES

Internet was not available at our location. We needed a tower/mast for rural point to point links that could be installed and serviced safely from the ground.

Anchoring it to structures and guy wires was not an option we wanted to include. We also wanted to avoid a costly reinforced concrete foundation.

________________________________________________

We designed the LM-4, a free standing five section tower/mast for 60 feet, easily extended to 75 feet that two men can install and is serviceable from the ground! The LM-4 is our most popular model.

_______________________________________________

We are offering additional models as we go and invite you to inquire to see if adjustments need to be made to meet your specific needs.

Quality should never be compromised. No matter what product you choose, you can feel confident that our products are of the highest caliber made right here in the USA.

Self Supporting Tower / Tilt-Over Mast by Beacon Pole - Unobtrusive Patented Design

SAFETY FIRST

Please read through the instructions before beginning this project. We recommend a licensed, well qualified contractor or Internet Service Provider be employed to install the self-supporting tower / tilt-over masts. However, Do It Yourself Installation Instructions are available which is the most economical option.

Installers must wear appropriate personal protective Safety Gear Including:

Steel Toed Shoes
Safety Glasses
Work Gloves
Hard Hat

Always consider that any tower/mast may fail in extreme circumstances. Never locate any tower/mast where it could fall and strike power lines or buildings.

Do Your Homework.

Get underground utilities marked before installation.
Mark pipes and electric cables before drilling or trenching.
Keep towers/masts away from power lines, height +15ft.
Bury and cement the ground pole to the minimum specified depth.
Ground the radio/antenna using a separate copper conductor and ground rod to local code.
Install lightning/power surge protection in Ethernet cable at base of pole and where it enters a building.
Do not overload the tower/mast with multiple or oversized antennas, lighting or cameras.

Keep Alert

Installation of any tower/mast should not be attempted in windy conditions. Don’t raise or lower tower/mast in more than a gentle breeze.
Always stand and work to the sides of the Cheek Plates. No one should stand under or in the path of the tower/mast while it is being assembled, raised, or lowered.
Inspect all tools, winch & accessories, cable, and ladder for wear or damage.

The DIY Installation Kit may be purchased separately for those who do not have all the tools to install. DIY Installation Instructions are also available and can be viewed under the DIY INSTALLATION tab, with a downloadable pdf option or emailed at your request. DIY is the most economical option.

Our Outstanding Customer Service Department is available Monday - Friday 8:00 am to 5:00 pm CST standing by and ready to assist you with your install either by phone at 1.800.842.7622 or email at beacon@b-pole.com.
